Ford Ranger Next Gen (T6.2 / P703) 3D scans and CAD files
4 products for the Ford Ranger Next Gen (T6.2 / P703): rear bumper fabrication plans, rear end STEP CAD model, front end STEP CAD model, chassis STEP CAD model; the files on sale fit model years 2022-2025 or 2022+, depending on the file. All 4 are on sale in our Etsy shop.
Also sold as: Ford Ranger 2022+ (Australia, Europe, Asia, Africa); Ford Ranger 2024+ (USA).
Guide: Ford Ranger Generations by Market: Same Year, Different Truck
Every Ford Ranger Next Gen (T6.2 / P703) file at a glance
| Dwg no | File | L × W × H, mm | Triangles | Formats | Download | Price | Summary |
|---|---|---|---|---|---|---|---|
| CGP-RANGERNG-RB-PLANS | 2022-2025 Rear Bumper Fabrication Plans | Fabrication plans, not a scan | IGES, DXF, PDF, STEP | 11.6 MB | $49.99 on Etsy: Ford Ranger Next Gen (T6.2 / P703) 2022-2025 Rear Bumper Fabrication Plans | Fabrication plans, not a scan · IGES, DXF, PDF, STEP · 11.6 MB | |
| CGP-RANGERNG-REAR-STEP | 2022+ Rear End STEP CAD Model | CAD model, size not measured yet | STEP | 360 MB | $80 on Etsy: Ford Ranger Next Gen (T6.2 / P703) 2022+ Rear End STEP CAD Model | CAD model, size not measured yet · STEP · 360 MB | |
| CGP-RANGERNG-FRONT-STEP | 2022+ Front End STEP CAD Model | CAD model, size not measured yet | STEP | 518 MB | $90 on Etsy: Ford Ranger Next Gen (T6.2 / P703) 2022+ Front End STEP CAD Model | CAD model, size not measured yet · STEP · 518 MB | |
| CGP-RANGERNG-CHASSIS-STEP | 2022+ Chassis STEP CAD Model | CAD model, size not measured yet | STEP | 248 MB | $90 on Etsy: Ford Ranger Next Gen (T6.2 / P703) 2022+ Chassis STEP CAD Model | CAD model, size not measured yet · STEP · 248 MB | |
Sizes are length × width × height of the file as measured, in millimeters at 1:1 scale, with the size in inches.
The files
CGP-RANGERNG-RB-PLANS $49.99
2022-2025 Rear Bumper Fabrication Plans
Plans, not a scan IGES, DXF, PDF, STEP · 11.6 MB download
CGP-RANGERNG-REAR-STEP $80
2022+ Rear End STEP CAD Model
Size not measured yet Triangles not measured yet STEP · 360 MB download
CGP-RANGERNG-FRONT-STEP $90
2022+ Front End STEP CAD Model
Size not measured yet Triangles not measured yet STEP · 518 MB download
CGP-RANGERNG-CHASSIS-STEP $90
2022+ Chassis STEP CAD Model
Size not measured yet Triangles not measured yet STEP · 248 MB download
